ماكينةفايبرليزرللقطاعاتوالمواسير
Round, square, rectangular, oval — any tube profile, precisely cut.
Heavy-duty rotary tube & pipe fiber laser cutter with integrated rotary axis. TubePro software, Raycus CE laser, Yaskawa servo motors, and HIWIN rails — for continuous production of any tube profile.
Key Features & Benefits
Integrated Rotary System
Round, square, rectangular, oval, and custom tube shapes.
TubePro Control Software
Intelligent path planning and compensation for complex angled cuts.
Raycus CE Fiber Laser
Stable, high-efficiency cutting with minimal heat-affected zones.
Auto-Focus BOCI Laser Head
Dynamically adjusts to tube thickness and shape.
Yaskawa Servo + Shimpo Reducers
Synchronized rotation and fast axis movement.
Optional Bevel Cutting
Advanced angled cut capability for complex joints.
Technical Specifications
Full specifications for the ماكينة فايبر ليزر للقطاعات والمواسير . Contact our team for custom configurations or application-specific requirements.
Download PDF| Laser Power | 3,000–12,000 W |
| Laser Type | Raycus CE / IPG |
| Chuck Diameter | Ø 90–350 mm (customizable) |
| Working Length | 1,500–12,000 mm (customizable) |
| Control System | FSCUT – TubePro |
| Max. Cutting Speed | 0–80 m/min |
| Max. Running Speed | 120 m/min |
| Axis Precision | ≤±0.05 mm/m |
| Repeat Precision | ≤±0.03 mm/m |
| Servo Motors | Yaskawa (Japan) |
Get a Quote for the ماكينة فايبر ليزر للقطاعات والمواسير
Contact our sales team for the best price and unit availability. We respond within hours.
